喉士母牙高壓頭

SAE JIC 37°
Commonly referred to as JIC
fittings, these metal-to-metal
sealing type fittings have a 37°
flare (sealing surface angle) and
straight United National Fine
Threads (UNF).

Standard: ISO 12151-5,
ISO8434-2, SAE J516

規格表

編號	牙	HOSE BORE	螺母H
A0302S2-0404	7/16"-20	1/4"	14
A0302S2-0405G	7/16"-20	5/16"	17
A0302S2-0406G	7/16"-20	3/8"	17
A0302S2-0504	1/2"20	1/4"	17
A0302S2-0604	9/16"-18	1/4"	19
A0301S1-0605	9/16"-18	5/16"	19
A0302S2-0606	9/16"-18	3/8"	19
A0302S2-0806	3/4"-16	3/8"	23
A0302S2-0808	3/4"-16	1/2"	23
A0302S2-1008	7/8"-14	1/2"	26
A0302S2-1010	7/8"-14	5/8"	26
A0302S2-1012G	7/8"-14	3/4"	27
A0302S2-1208	１1/16"-12	1/2"	32
A0302S2-1210	１1/16"-12	5/8"	32
A0302S2-1212	１1/16"-12	3/4"	32
A0302S2-1216G	１1/16"-12	１"	32
A0302S2-1612	１5/16"-12	3/4"	38
A0302S2-1614	１5/16"-12	7/8"	38
A0302S2-1616	１5/16"-12	１"	38
A0302S2-2016	１5/8"-12	１"	50
A0302S2-2020	１5/8"-12	１1/4"	50
A0302S2-2424	１7/8"-12	１1/2"	57
A0302S2-2828	２1/4"-12	２"	68
A0302S2-3232	２1/2"-12	２"	72

＊可搭配S2、S3（大）、S8（特大）及SLY4（4S）的高壓殼使用

產品規格表 (必須輸入標題才可顯示內容)

PART NUMBER	HOSE END	Thread	X mm	Y mm	L mm	Weight (g)
A0302S2-0404	1/4"	7/16"-20	14	14
A0302S2-0406G	3/8"	7/16"-20	17	19
A0302S2-0604	3/8"	9/16"-18	19	19
A0302S2-0606	3/8"	9/16"-18	19	19
A0302S2-0608G	1/2"	9/16"-18	22	22
A0302S2-0806	3/8"	3/4"-16	23	19
A0302S2-0808	1/2"	3/4"-16	23	23
A0302S2-1008	5/8"	7/8"-14	26	23
A0302S2-1010	5/8"	7/8"-14	26	26
A0302S2-1210	5/8"	１1/16"-12	32	26
A0302S2-1212	3/4"	１1/16"-12	32	32
A0302S2-1216	１"	１1/16"-12	32	38
A0302S2-1612	3/4"	１5/16"-12	38	32
A0302S2-1616	１"	１5/16"-12	38	38
A0302S2-2016	１"	１5/8"-12	50	38
A0302S2-2020	１1/4"	１5/8"-12	50	50
A0302S2-2424	１1/2"	１7/8"-12	57	57
A0302S2-2828	２"	１7/8"-12	68	68
A0302S2-3232	２"	２1/2"-12	72	72
